CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift

Chứng nhận
Trung Quốc Shandong Lift Machinery Co.,Ltd Chứng chỉ
Trung Quốc Shandong Lift Machinery Co.,Ltd Chứng chỉ
Khách hàng đánh giá
I came to order, I saw a very large factory with professional advanced equipment,clean workshop, first-class raw materials, a very trustable supplier!

—— Mr. Marc - Belgium

Very professional for products. Very good services during the order!

—— Mr. James - Australia

Exclent Lift Platform Lift ! Professional Saler ! Good Business with Shandong Lift.

—— Mr. Mushi - India

Kinh doanh rất tốt với thang máy Shandong! Sẽ hợp tác ngày càng nhiều trong tương lai!

—— Ông Bruce - New Zealand

Tôi trò chuyện trực tuyến bây giờ

CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift

CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift
CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift

Hình ảnh lớn :  CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: SDLIFT Or OEM
Chứng nhận: CE TUV SGS
Model Number: SJG5-4.5
Thanh toán:
Minimum Order Quantity: 1 UNIT
Giá bán: USD3980- USD7800 / UNIT
Packaging Details: Iron case or plywood case package
Delivery Time: 5-20 work days
Supply Ability: 3600units per year

CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift

Sự miêu tả
Application: Scissor Lift For Cargo Lift Safe Device: Explosion-Proof Lock Valve
Lift Drive: Hydraulic Scissor Lift Motor: From Italy or Chinese famous brand
Material: high strength Manganese Steel Lift System: Hydraulic System
Power Supply: 380v/50hz/3ph/3.0kw Color: red, grey, yellow, blue, or as your optional
Structure: scissor lift structure Loading capacity: 2000kgs
Lifting/travel height: 4200mm Platform size: 2200mm x 1800mm
Điểm nổi bật:

material handling lifts

,

hydraulic lift platform

CE TUV 2T Hydraulic Material Scissor Lift Platform Warehouse Cargo Scissor Lift:





Application:



The Hydraulic scissor lift can be used to lift cargo with different levels, suitable for cargo between stairs, from basement to first floor, to second floor, or to third floor.

Operation is easy. There are 2 sets control system installed on the Hydraulic scissor car lift , 1 control box below, and 1 hand controller on safety rail that can be operated on upper platform.



Advantages:



Hydraulic lifting system, the far-end control and multi-control points at the different floors could be realized hierarchical control. Stop anywhere at the pre-concerted and accurate location point. It can work under any condition, great load capacity, safe and reliable. There are sensitive overload protection locking device to avoid falling for the Hydraulic scissor lift.



Parts showing:



CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift 0



The models we supplied for clients:





MODEL LOAD CAPACITY PLATFORM SIZE LIFT HEIGHT PIT DEPTH POWER
SJG2.5-3 2.5T 5.2m x 2.6m 3m 750mm 220V, 240V, 380V or 400V
SJG2-6.5 2T 5.2m x 2.8m 6.5m 800mm 220V, 240V, 380V or 400V
SJG2.5-3.5 2.5T 5.2m x 2.6m 3.5m 800mm 220V, 240V, 380V or 400V
SJG2.5-5 2.5T 5.6m x 3m 5m 800mm 220V, 240V, 380V or 400V
SJG3-2.5 3T 5m x 2.3m 2.5m 750mm 220V, 240V, 380V or 400V
SJG3-3 3T 5.2m x 2.6m 3m 800mm 220V, 240V, 380V or 400V
SJG3-3.5 3T 5.6m x 2.7m 3.5m 800mm 220V, 240V, 380V or 400V
SJG5-10 5T 4.5m x 2.5m 10m 1150mm 220V, 240V, 380V or 400V
SJG8-2.5 8T 6.5m x 4.5m 2.5m 850mm 220V, 240V, 380V or 400V
SJG12-3 12T 5.5m x 2.8m 3m 950mm 220V, 240V, 380V or 400V
SJG15-4.5 15T 8m x 2.2m 4.5m 1150mm 220V, 240V, 380V or 400V
SJG20-5 20T 6m x 3m 5m 1200mm 220V, 240V, 380V or 400V
The Hydraulic scissor lift can be customized as your detailed size.



Safety:


1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs
2) The safety guard rails to guarantee safety of the cargo above platform
3) The limit switch system helps the hydraulic scissor liftto stop at accurate position
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the hydraulic scissor lift  are passed 1.2 times loading test before leaving factory.



Configuration:



1) Platform Material:  rectangular tube + 4mm checkered iron

2) Scissor material:  high strength Manganese Steel.

3) Hydraulic system: 380V/3.0Kw

4) High Precision Hydraulic Cylinder: 2pcs

5) Piston Rod:  hard chromium plating surface.

6) High-pressure oil pump

7) Hydraulic oil: summer 46#, winter 32#

8) Controller: 1 control box below, 1 control panel above platform



Products showing:



CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift 1

CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift 2





Packaging & Shipping:



CE TUV 2T Stationary Hydraulic Scissor Lift Platform Warehouse Cargo Scissor Lift 3
